How tpm-ca-certificates Works: Principles and Tools

The Principles

When I started designing the project, I wanted it to follow a number of principles to ensure its reliability, security, and ease of use.

Let’s look at them more closely.

1. An open-source project

The project is free and open, which allows the community to contribute, audit the code, and ensure its transparency.

2. A declaratively generated bundle

Each bundle is built from a human-readable configuration. The project stores two files ¹ at its root: the first for root certificates (self-signed) and the second for intermediate certificates.

Please find below a snippet:

vendors:
    - id: "AMD"
      name: "AMD"
      certificates:
        - name: "AMD Pluton Global Factory ICA"
          uri: "https://ftpm.amd.com/hsp/ica/AMD-Pluton-Global-Factory-ICA.crt"
          validation:
            fingerprint:
                sha256: "59:3A:17:94:F9:E1:74:76:C7:AD:42:7D:29:08:A9:7C:45:14:51:C9:E0:93:9F:DC:80:D5:D6:62:C2:32:D4:01"

As you can see, the configuration places the provenance of a certificate as a central element.

It was essential for me to guarantee total transparency about the origin of certificates, which is why (apart from exceptions) the repo stores no certificates.

Since resources are remote, an integrity verification mechanism is essential. This is why adding a new certificate is accompanied by generating a fingerprint.

3. A reproducible bundle

The third principle is to ensure that each publicly generated bundle can be reproduced identically from its original configuration.

To do this, tpm-ca-certificates provides a CLI named tpmtb² which allows (among other things) to generate the bundle from the configuration.

To validate integrity, it’s simple, just run the commands below:

git clone https://github.com/loicsikidi/tpm-ca-certificates
cd tpm-ca-certificates
RELEASE_DATE=2026-05-19 # latest release (at the time of writing)
git checkout $RELEASE_DATE # YYYY-MM-DD
go run ./ bundle generate --config .tpm-roots.yaml --output tpm-ca-certificates.pem --workers 10
go run ./ bundle generate --config .tpm-intermediates.yaml --output tpm-intermediate-ca-certificates.pem --workers 10
sha256sum tpm-ca-certificates.pem  tpm-intermediate-ca-certificates.pem # Compare with released checksum

4. Proof of inclusion

To submit a new certificate to one of the bundles, it’s necessary to provide proof (e.g., an official link, a PDF, etc.) to justify its inclusion. The various proofs are compiled in the src/ directory and ensure transparency and audit of included certificates.

5. A bundle in a standard (and practical) format

The project generates the bundle in PEM format.

After careful consideration, I chose this format for two reasons:

1. it’s compatible with the majority of existing tools and libraries.
2. it allows adding metadata
   • useful for adding information for users (transparency, audit, etc.)
   • useful to add business logic (e.g., filtering, search, etc.)

Find below a snippet of the generated bundle:

##
## tpm-ca-certificates.pem
##
## Date: 2026-04-11
## Commit: 7e245bcd7c6a19e92df9656f00a796765e875808
##
## This file has been auto-generated by tpmtb (TPM Trust Bundle)
## and contains a list of verified TPM Root Endorsement Certificates.
##

#
# Certificate: AMDTPM ECC
# Owner: AMD
#
# Issuer: CN=AMDTPM,OU=Engineering,O=Advanced Micro Devices,L=Sunnyvale,ST=CA,C=US
# Serial Number: 46881938082510745600952034594836025327 (0x23452201d41c5ab064032bd23f158fef)
# Subject: CN=AMDTPM,OU=Engineering,O=Advanced Micro Devices,L=Sunnyvale,ST=CA,C=US
# Not Valid Before: Fri Jan 01 05:00:00 2016
# Not Valid After : Tue Jan 01 05:00:00 2041
# Fingerprint (SHA-256): C2:CB:57:BF:72:3C:17:4F:16:6C:5A:A1:DC:64:16:09:81:05:4B:EE:18:C7:0E:B1:DE:BF:C1:51:8A:FA:92:D2
# Fingerprint (SHA1): 8F:A1:A2:BD:F9:09:7D:41:4C:A0:EE:62:42:89:5C:0A:75:2A:D7:D1
-----BEGIN CERTIFICATE-----
....
-----END CERTIFICATE-----

We can see that the bundle contains global metadata (generation date, commit, etc.) and information specific to each certificate (owner, issuer, validity period, fingerprints, etc.).

The available tools

For the above principles to be embodied, the repo provides a CLI named tpmtb² which allows:

1. to manage the bundle configuration file (addition, deletion, validation, formatting)
2. to generate the bundle
3. to list and download different versions of the bundle

In addition, the core logic is held in a Golang SDK and the CLI is built on top of it.

Any Go application willing to interact with the TPM trust bundle can leverage this SDK.

You can find the SDK documentation here.

How release process works

When a new version of the bundle is ready, a tag is created (following the format YYYY-MM-DD) and a publication pipeline is triggered.

Once completed, the root and intermediate bundles are published publicly as GitHub artifacts.

Conclusion

In this post, we’ve seen that the project relies on several pillars:

• transparency ➡️ open source + the provenance of each certificate is documented in the configuration
• reproducibility ➡️ anyone can regenerate the bundle from the configuration

There’s a third one that I deliberately omitted until now: integrity. Indeed, how do we ensure the bundle is intact and was actually produced by the repo in a secure context? This is what we’ll address in the next post.

Note: image generated by ChatGPT
